Workstation configurator - AMD Threadripper PRO (So. sTR5)
AMD Ryzen Threadripper PRO 9000
Max. 768GB DDR5 ECC RAM
Up to 96 cores
9.299
,-
incl. VAT plusShipping
169
,83
Delivery time:
4-6 Werktage
3 year warranty
Lifetime support
30-day return policy
/month
3-year warranty,
including pickup and return
Lifetime
Support
Professional
assembly
Rigorous testing and
quality control
Workstation configurator
AMD Threadripper PRO (So. sTR5)
Here you have the opportunity to put together your own personal workstation configuration based on modern AMD Threadripper 9000 PRO (So. sTR5) processors. The system is always delivered fully assembled and tested, with a full warranty.
Our workstation configurator automatically detects compatibility issues, so that incorrect configuration is virtually impossible. Regardless of this, you can of course call our support team at any time for free advice and configure your desired PC online with the help of our support team. Even as a complete layman!
Every configuration is checked by us when the order is received. We will contact you immediately if there are any problems with the system you have ordered.
Important: The absence of components not included in the basic configuration is not considered an error by us - so you do not necessarily have to order a graphics card, hard disk, etc. In this way, we give you the option of upgrading the system yourself with components that you already have or have ordered elsewhere. However, overclocking can ONLY be set in conjunction with ordering a RAM.
Have fun configuring!
High-end workstation based on AMD Threadripper PRO 9000 for optimum performance in deep learning and other HPC workloads.
Technical details
Workstation configurator - AMD Threadripper PRO (So. sTR5)
- Fractal Design Define 7 XL, black | soundproofedThe Define 7 XL is the next milestone in the world-renowned Define series and sets new standards in terms of what you can expect from a big tower case in terms of modularity, flexibility and ease of use. A flexible dual layout, the high-quality sound insulation and the timeless, minimalist design make the Define 7 XL the ideal choice for PC users with high demands on design, functionality and versatility.
Technical details - Connections (CHA)1x USB-C 3.1 (10Gb/s, 20-pin Key-A header), 2x USB-A 3.0 (5Gb/s), 2x USB-A 2.0 (480Mb/s), 1x 3.5mm jack (line-out), 1x 3.5mm jack (line-in)
- Number of PCIe slots12 (3x Riser Card)
- DesignFull-Tower
- Mainboard compatibilityMini-ITX (6.7 "x6.7")/µATX (9.6 "x9.6")/ATX (12 "x9.6")/E-ATX (SSI CEB, 12 "x10.5")/E-ATX (SSI EEB, 12 "x13")/EE-ATX (13.68 "x13")
- Fan (front)2x 140mm, 1000rpm, 116m³/h (68.27 CFM), 18.9dB(A) or 3x 140mm (optional) or 4x 120mm (optional)
- Fan (rear)1x 140mm, 1000rpm, 116m³/h (68.27 CFM), 18.9dB(A)
- Fan (top)3x 140mm (optional) or 4x 120mm (optional)
- Fan (lateral)-
- Fan (bottom)2x 140mm (optional)
- Internal drive bays6x 2.5"/3.5" (horizontal, drive rails), 2x 2.5"
- ManufacturerFractal
- Lighting-
- Dimensions (WxHxD)240x566x604mm
- Special featuresFront door, incl. fan control, graphics card can be mounted vertically, soundproofed
- AMD Ryzen Threadripper PRO 9965WX, 24x 4.2GHz, 128MB L3 cacheEnhance workstation performance for maximum productivity - From blockbuster movies to ambitious architecture and next-gen designs, bring your ideas to life quickly with the ultimate workstation performance of AMD Ryzen Threadripper PRO 9000 WX-Series processors.
Technical details - Processor cores24
- BaseAMD sTR5
- Processor threads48
- Base clock4.20 GHz
- Turbo beat5.40 GHz
- L2 cache24MB (24x 1MB)
- L3 cache128MB (4x 32MB)
- TDP350 Watt
- iGPU type (label)N/A
- PCIe lanes128x PCIe 5.0, 16x PCIe 4.0
- Memory controller8 Channel DDR5-6400 RDIMM (PC5-51200, 409.6GB/s), max. 2TB
- ManufacturingZen 5
- Code nameShimada Peak
- ASUS Pro WS WRX90E-Sage SE | AMD WRX90
Technical details - Processor socketAMD sTR5
- RAM support8x DDR5 DIMM, octa PC5-41600R/DDR5-5200, max. 2TB (RDIMM-3DS)
- Wireless standardsN/A
- Form factorE-ATX (SSI EEB)
- ChipsetAMD WRX90
- LightingN/A
- Special featuresAudio+solid capacitors, Diagnostic LED (segment display), 1x M.2 active cooler, 3x M.2 passive coolers, integrated I/O panel, voltage measuring points, backplate, ECC support, support for 2 power supplies, onboard TPM 2.0 support (AMD fTPM, see additional manufacturer link)
- Power supply1x 24-pin ATX (PSU1), 2x 8-pin EPS12V, 3x 8-pin PCIe, 1x 8-pin PCIe
- FAN header2x CPU fan 4-pin, 6x fans, 1x pump 4-pin, 3x 4-pin proprietary (occupied), 1x thermal sensor
- Audio description7.1 (Realtek ALC1220)
- Connections (rear)1x VGA (AST2600), 2x USB4 (40Gb/s, ASMedia ASM4242), 6x USB-A 3.1 (10Gb/s), 1x USB-A 2.0 (480Mb/s), 2x 10GBase-T (Intel), 2x jack, 2x DisplayPort-In (Mini DisplayPort), 1x management port (RJ-45)
- Internal connections1x USB-C 3.2 Key-A Header (20Gb/​s), 1x USB 3.0 Header (5Gb/​s, 2x USB 3.0), 2x USB 2.0 Header (480Mb/​s, 4x USB 2.0), 4x SATA 6Gb/s (WRX90), 1x seriell, 1x Cardreader (microSD), 1x TPM-Header, 1x Chassis Intrusion-Header, 1x BMC-Header, 1x Message LED Header, 2x LAN LED Header, 1x Location LED Header, 1x Location Button Header, 1x PSU SMB Header, 1x VGA-Header, 1x VPP I2C Header
- RAID level0/​1/​10 (WRX90)
- Expansion slots7x PCIe 5.0 x16 (6x x16, 1x x8), 2x M.2/M-Key (PCIe 5.0 x4, 22110/2280/2260/2242), 2x M.2/M-Key (PCIe 5.0 x4, 2280/2260/2242), 1x M.2/E-Key (PCIe, 2230), 2x Slim SAS SFF-8654 (PCIe 4.0 x4)
- RGB headerN/​A
- NVIDIA RTX A400, 4GB
Technical details - Memory type4GB GDDR6, 64bit, 10Gbps, 1250MHz, 80GB/s
- API supportDirectX 12 (12_1) /​ CUDA 7.5 /​ Vulkan 1.3 /​ OpenCL 3.0 /​ OpenGL 4.6 /​ Shader Model 6.7
- PCIe cut pointPCIe 3.0 x16
- GPU typeNVIDIA RTX A400 4Go
- VRAM4GB
- GPU clock420MHz
- GPU clock (boost)1425MHz
- GPU fan1x axial fan (50mm)
- Power consumption30W (NVIDIA)
- Dimensions (WxHxD)156x69mm (LxW)
- Special featuresN/A
- Power supplyN/A
- Connections (rear)4x Mini DisplayPort 1.4a
- 16GB RDIMM ECC DDR5-5600DDR5 with ECC error correction: Ensure the highest data integrity and uninterrupted performance. DDR5 ECC RAM not only offers the bandwidth of the latest memory generation, but also the protection against memory errors that is essential for professional and business-critical systems.
Technical details - RAM type designationDDR5 RDIMM 288-pin, reg ECC, on-die ECC
- RAM size1x 16GB
- RAM total16GB
- Memory clock Label5600MT/s
- Latency46
- RAM coolingN/A
- Special featuresStandard SPD
- Noctua NH-U14S TR5-SP6Noctua NH-U14S TR5/SP6: The customized cooling solution for AMD's TR5/SP6 socket. Delivers Noctua's renowned cooling performance and reliability for your high-end Threadripper or EPYC based systems.
Technical details - Heatpipes6 heat pipes
- Fan2x 140x140x25mm, 300-1500rpm, 140.2m³/h, 82.51 CFM, 24.6dB(A), 2.08mmH₂O, 1.56W (NF-A15 HS-PWM, Link)
- Socket AMDsTR5/​SP6
- Socket Intel-
- TDP-
- Lighting-
- Dimensions (WxHxD)150x165x111mm (WxHxD)
- Special features-
- 500GB brand M.2 SSDNVMe M.2 SSD
Technical details - Memory typedepending on model
- Storage capacity500GB
- Interfaceje nach Modell
- Reading speeddepending on model
- Write speeddepending on model
- SSD controller-
- Mean time between failuresdepending on model
- IOPS 4Kdepending on model
- Power supplydepending on model
- 850W - be quiet! Power Zone | modular
Technical details - PSU power (Desc)850W
- Power 12V70.8A
- Power 3.3V20A
- Power 5V20A
- Power -12V0.3A
- PSU certification80 PLUS Platinum
- Fan140mm, 1800rpm, semi-passive
- Volume6.50-24.90dB(A) (according to manufacturer), 19.84dB(A) (according to Cybenetics certificate, 115V), 19.31dB(A) (according to Cybenetics certificate, 230V)
- Form factorATX
- Special featuresErP Lot 6, supports Haswell C6/C7 low-power states
- 3-year warranty | incl. pick-up & returnWe grant a 3-year warranty on the delivered PC from the date of delivery, including free pick-up & return service in Germany, Austria and Switzerland. If material or manufacturing defects occur during this period, which significantly impair your work with the PC, we will pick up the defective PC or only the defective component (so that you can continue to work with the PC all the time under certain circumstances) free of charge, repair or replace the PC and then make the PC available to you again. Peripherals and accessories (e.g. monitors etc.) are covered by the manufacturer's warranty.
Technical details - Warranty period3 years
- Pick-up and return service3 years
- Telephone supportYes
- Callback serviceYes
- E-mail supportYes
Dimensions
WIDTH x HEIGHT x DEPTH
240x566x604mm
Connectivity
Front
1x USB-C 3.1 (10Gb/s, 20-pin Key-A header), 2x USB-A 3.0 (5Gb/s), 2x USB-A 2.0 (480Mb/s), 1x 3.5mm jack (line-out), 1x 3.5mm jack (line-in)
Rear
1x VGA (AST2600), 2x USB4 (40Gb/s, ASMedia ASM4242), 6x USB-A 3.1 (10Gb/s), 1x USB-A 2.0 (480Mb/s), 2x 10GBase-T (Intel), 2x jack, 2x DisplayPort-In (Mini DisplayPort), 1x management port (RJ-45), 4x Mini DisplayPort 1.4a
