Silent PC Configurator - AMD Ryzen 9000 (So. AM5)
999
,-
incl. VAT plusShipping
18
,24
Delivery time:
5-7 business days
3 year warranty
Lifetime support
30-day return policy
/month
3-year warranty,
including pickup and return
Lifetime
Support
Professional
assembly
Rigorous testing and
quality control
Silent PC Configurator
AMD Ryzen 9000 (So. AM5)
Our PC configurator automatically detects compatibility problems, so that incorrect configuration is virtually impossible. Regardless of this, you can of course call our support team at any time for free advice and configure your desired PC online with the help of our support team. Even as a complete layman!
Every configuration is checked by us when the order is received. We will contact you immediately if there are any problems with the system you have ordered.
Important: We do not consider the absence of components not included in the basic configuration to be a fault - so you do not necessarily have to order a graphics card, hard disk, etc. In this way, we give you the option of upgrading the system yourself with components that you already have or have ordered elsewhere.
Have fun configuring!
The comprehensive gaming PC configurator for AMD AM4
Technical details
Silent PC Configurator - AMD Ryzen 9000 (So. AM5)
- be quiet! Pure Base 501, black | soundproofedPure Base 501 proves that simple can also be exciting. Useful features and a compact size make this case perfect for any gaming or office PC. If you're looking for a PC case with compact dimensions, a surprising number of features and space for large components, you've found it: The Pure Base 501 is your choice. And you can express yourself individually: The Pure Base 501 in black is available with a mesh or closed front panel and also in white with a mesh panel for excellent airflow. All mesh variants are available with a side window or closed side panel.
Technical details - Connections (CHA)1x USB-C 3.1 (10Gb/s, 20-pin Key-A header), 1x USB-A 3.0 (5Gb/s), 1x 3.5mm jack (line-out), 1x 3.5mm jack (line-in)
- Number of PCIe slots7
- DesignMidi-Tower
- Mainboard compatibilityMini-ITX (6.7 "x6.7")/µATX (9.6 "x9.6")/ATX (12 "x9.6")
- Fan (front)1x 140mm, 1200rpm, 0.96mmH₂O, 97.53m³/h (57.4 CFM), 21.9dB(A) (Pure Wings 3 PWM 140mm) or 2x 140mm (optional) or 3x 120mm (optional)
- Fan (rear)1x 140mm, 1200rpm, 0.96mmH₂O, 97.53m³/h (57.4 CFM), 21.9dB(A) (Pure Wings 3 PWM 140mm) or 1x 120mm (optional)
- Fan (top)2x 140mm (optional) or 2x 120mm (optional)
- Fan (lateral)-
- Fan (bottom)-
- Internal drive bays1x 2.5"/3.5" (landscape, hard disk cage), 1x 3.5" (landscape, hard disk cage), 4x 2.5"
- Manufacturerbe quiet!
- Lighting-
- Dimensions (WxHxD)231x463x450mm
- Special featuresCable management, dust filter
- AMD Ryzen 5 7600X, 6x 4.7GHzThe latest generation of AMD processors offer an impressive combination of performance, efficiency and future-proofing, which is particularly interesting for gamers. Thanks to the advanced Zen architecture, the current models impress with high single-core performance, which often makes the decisive difference in modern games. At the same time, many cores and threads ensure strong multitasking capability, ideal for streaming, content creation and demanding applications in the background.
Technical details - Processor cores6 (6C)
- BaseAMD AM5 (LGA1718)
- Processor threads12
- Base clock4.70GHz
- Turbo beat5.30GHz
- L2 cache6MB (6x 1MB)
- L3 cache32MB
- TDP105W
- iGPU type (label)AMD Radeon Graphics
- PCIe lanes24x PCIe 5.0
- Memory controllerDual Channel DDR5-5200 (PC5-41600), 83.2GB/s, max. 192GB (UEFI AGESA Basis 1.0.0.7 or higher)
- ManufacturingZen 4
- Code nameRaphael-X
- ASUS TUF Gaming B650-E WIFI | AMD B650AMD B650 motherboards offer a solid all-round solution for anyone who wants to build a powerful and future-proof system. They support the latest Ryzen processors with AM5 sockets and thus offer a modern platform for gaming, streaming and everyday applications. Thanks to PCIe 5.0 and DDR5 compatibility, they are technically up to date and enable fast data transfer and short loading times in games.
Technical details - Processor socketAMD AM5
- RAM supportDDR5-5200 (Ryzen 7000), DDR5-5200 (Ryzen 8000G), DDR5-5600 (Ryzen 9000)
- Wireless standardsWi-Fi 6E (WLAN 802.11a/b/g/n/ac/ax, 2x2, Realtek RTL8852CE), Bluetooth 5.3
- Form factorATX
- ChipsetAMD B650
- Lighting-
- Special featuresAudio+solid capacitors, Diagnostic LED (LED indicators), integrated I/O panel, 1x M.2 passive cooler
- ColorSchwarz
- Power supply1x 24-pin ATX, 1x 8-pin EPS12V, 1x 4-pin ATX12V
- FAN header2x CPU fan 4-pin, 4x fan 4-pin, 1x AIO pump 4-pin
- Audio descriptionRealtek ALC897
- Connections (rear)1x HDMI 2.1 (iGPU), 1x DisplayPort 1.4 (iGPU), 1x USB-C 3.1 (10Gb/s), 1x USB-A 3.1 (10Gb/s), 3x USB-A 3.0 (5Gb/s), 3x USB-A 2.0 (480Mb/s), 1x RJ-45 2.5Gb LAN (Realtek), 3x 3.5mm jack (Realtek ALC897), 2x antenna connection RP-SMA
- Internal connections1x USB-C 3.2 Key-A Header (20Gb/​s), 1x USB 3.0 Header 20-Pin (5Gb/​s, 2x USB 3.0), 2x USB 2.0 Header 9-Pin (480Mb/​s, 4x USB 2.0), 4x SATA 6Gb/s (B650)
- RAID level0/​1/​10 (B650)
- Expansion slots2x PCIe 4.0 x16 (1x x16, 1x x1), 1x PCIe 4.0 x1, 1x M.2/M-Key (PCIe 5.0 x4, 2280/2260/2242), 1x M.2/M-Key (PCIe 4.0 x4, 2280/2260/2242), 1x M.2/M-Key (PCIe 4.0 x4, 22110/2280/2260/2242), 1x M.2/E-Key (2230, occupied with WiFi+BT module)
- RGB header1x 4-Pin RGB (+12V/​G/​R/​B, max. 3A), 3x 3-Pin ARGB (+5V/​DATA/​GND, max. 3A, ASUS Gen2)
- 16GB Corsair Vengeance RGB DDR5-6000 | 1x 16GBThe Corsair Vengeance memory is one of the most popular RAM series among gamers and offers an excellent combination of performance, stability and design. With high clock rates and low latencies, it ensures that modern games run smoothly and enable short loading times - even in combination with demanding processors and graphics cards.
Technical details - RAM type designationDDR5 DIMM 288-pin, on-die ECC
- RAM size1x 16GB
- RAM total16GB
- Memory clock Label6000MHz
- Latency36
- RAM coolingHeatspreader
- Special featuresRGB, Multi-Zone, 10 LED, Corsair iCUE, Gigabyte RGB Fusion, MSI Mystic Light Sync
- DeepCool AK500 MIFCOM Black | 120mm fanThe DeepCool AK500 is a powerful tower cooler that has been specially developed for modern gaming and workstation systems. With its massive cooling surface, an asymmetrical heat sink design and a high-quality 120 mm fan, it offers impressive heat dissipation - ideal for powerful multi-core processors, even under continuous load.
Technical details - Heatpipes5 heatpipes (6mm)
- TDP240W
- Lighting-
- Dimensions (WxHxD)127x158x117mm (WxHxD)
- Special features-
- Fan1x 120x120x25mm, 500-1850rpm, 117.28m³/h, 69.02 CFM, 31.5dB(A), 2.19mmH₂O, hydrodynamic plain bearing (FDB)
- Socket AMDAM5, AM4
- Socket Intel1851/​1700
- 500GB brand M.2 SSDNVMe M.2 SSD
Technical details - Memory typedepending on model
- Storage capacity500GB
- Interfaceje nach Modell
- Reading speeddepending on model
- Write speeddepending on model
- SSD controller-
- Mean time between failuresdepending on model
- IOPS 4Kdepending on model
- Power supplydepending on model
- 750W - be quiet! Pure Power 13 M | modular
Technical details - PSU power (Desc)750W
- Power 12V62.5A
- Power 3.3V20A
- Power 5V20A
- Power -12V0.3A
- PSU certification80 PLUS Gold
- Fan120mm, 1800rpm, semi-passive
- Volume0-20.80dB(A) (according to manufacturer)
- Form factorATX
- Special featuresErP Lot 6, supports Haswell C6/C7 low-power states
- 3-year warranty | incl. pick-up & returnWe grant a 3-year warranty on the delivered PC from the date of delivery, including free pick-up & return service in Germany, Austria and Switzerland. If material or manufacturing defects occur during this period, which significantly impair your work with the PC, we will pick up the defective PC or only the defective component (so that you can continue to work with the PC all the time under certain circumstances) free of charge, repair or replace the PC and then make the PC available to you again. Peripherals and accessories (e.g. monitors etc.) are covered by the manufacturer's warranty.
Technical details - Warranty period3 years
- Pick-up and return service3 years
- Telephone supportYes
- Callback serviceYes
- E-mail supportYes
Dimensions
WIDTH x HEIGHT x DEPTH
231x463x450mm
Connectivity
Front
1x USB-C 3.1 (10Gb/s, 20-pin Key-A header), 1x USB-A 3.0 (5Gb/s), 1x 3.5mm jack (line-out), 1x 3.5mm jack (line-in)
Rear
1x HDMI 2.1 (iGPU), 1x DisplayPort 1.4 (iGPU), 1x USB-C 3.1 (10Gb/s), 1x USB-A 3.1 (10Gb/s), 3x USB-A 3.0 (5Gb/s), 3x USB-A 2.0 (480Mb/s), 1x RJ-45 2.5Gb LAN (Realtek), 3x 3.5mm jack (Realtek ALC897), 2x antenna connection RP-SMA
