Mini Gaming PC Configurator - Intel Core Ultra (So. 1851)
Intel So. 1851
Intel Core Ultra
Max. 8C+16c
Max. 128GB DDR5 RAM
1.349
,-
incl. VAT plusShipping
24
,63
Delivery time:
7-9 business days
3 year warranty
Lifetime support
>20 years of experience
/month
3-year warranty,
including pickup and return
Lifetime
Support
Professional
assembly
Rigorous testing and
quality control
Mini Gaming PC Configurator
Intel Core Ultra (So. 1851)
Our PC configurator automatically detects compatibility problems, so that incorrect configuration is virtually impossible. Regardless of this, you can of course call our support team at any time for free advice and configure your desired PC online with the help of our support team. Even as a complete layman!
Every configuration is checked by us when the order is received. We will contact you immediately if there are any problems with the system you have ordered.
Important: We do not consider the absence of components not included in the basic configuration to be a fault - so you do not necessarily have to order a graphics card, hard disk, etc. In this way, we give you the option of upgrading the system yourself with components that you already have or have ordered elsewhere.
Have fun configuring!
The comprehensive Mini Gaming PC Configurator for Intel Core Ultra
Technical details
Mini Gaming PC Configurator - Intel Core Ultra (So. 1851)
- Lian Li DAN Cases A3, black
Technical details - Connections (CHA)1x USB-C 3.1 via USB header Key-A, 2x USB-A 3.0, 1x 3.5mm jack line-out, 1x 3.5mm jack line-in
- Number of PCIe slots4
- DesignMini-Tower
- Mainboard compatibilityMini-ITX (6.7 "x6.7")/µATX (9.6 "x9.6")
- Fan (front)3x 120mm (optional) or 2x 140mm (optional)
- Fan (rear)1x 120mm
- Fan (top)3x 120mm (optional) or 2x 140mm (optional)
- Fan (lateral)-
- Fan (bottom)2x 120mm (optional)
- Internal drive bays1x 2.5", 3x 2.5"/3.5"
- ManufacturerLian Li
- Lighting-
- Dimensions (WxHxD)194x321.5x443mm
- Special features-
- Intel Core Ultra 5 225F, 6C + 4cThe new Intel Arrow Lake processors for socket 1851 mark a significant step towards efficiency and modern system architecture. Compared to the previous generation, both power consumption and waste heat have been noticeably reduced - without compromising on computing power. This is a clear advantage, especially for gamers who rely on quiet and energy-efficient systems.
Technical details - Processor cores10 (6C+4c)
- BaseIntel 1851 (LGA1851)
- Processor threads10 (6+4)
- Base clock3.30GHz (P-Core), 2.70GHz (E-Core)
- Turbo beat4.90GHz (Turbo Boost 2.0), 4.90GHz (P-Core), 4.40GHz (E-Core)
- L2 cache22MB (6x 3MB + 1x 4MB)
- L3 cache22MB
- TDP65W (Processor Base Power), 121W (Maximum Turbo Power)
- iGPU type (label)-
- PCIe lanes20x PCIe 5.0, 4x PCIe 4.0
- Memory controllerDual Channel DDR5-5600 UDIMM (PC5-44800, 89.6GB/s), max. DDR5-6400 CUDIMM (PC5-51200, 102.4GB/s), max. 192GB
- ManufacturingTSMC 3nm
- Code nameArrow Lake-S
- Gigabyte B860M AORUS Elite WIFI6E | Intel B860Intel B860 motherboards offer a reliable and price-conscious platform for gaming systems that need to deliver solid performance even without a high-end budget. They support the latest generation of Intel processors and are ideal for users who value modern technology and stability without having to rely on expensive additional features.
Technical details - Processor socketIntel 1851
- RAM support4x DDR5 DIMM, Dual Channel, UDIMM (Non-ECC)/CUDIMM, max. 256GB (UDIMM), 256GB (CUDIMM)
- Wireless standardsWi-Fi 6E (WLAN 802.11a/b/g/n/ac/ax, 2x2), Bluetooth 5.3 (Intel AX211 or Realtek RTL8852CE)
- Form factormATX
- ChipsetIntel B860
- LightingRGB, 1 zone (chipset cooler)
- Special featuresAudio+solid capacitors, Diagnostic LED (LED indicators), integrated I/O panel, 3x M.2 passive coolers
- Power supply1x 24-pin ATX, 2x 8-pin EPS12V
- FAN header1x CPU fan 4-pin PWM, 1x CPU fan/pump 4-pin PWM, 3x fan 4-pin PWM, 1x fan/pump 4-pin PWM
- Audio descriptionRealtek ALC1220
- Connections (rear)1x HDMI 2.1 (HDCP 2.3, iGPU), 1x DisplayPort 2.1 (iGPU), 1x USB4 with DisplayPort 2.1 (40Gb/s, iGPU), 2x USB-A 3.1 (10Gb/s), 4x USB-A 3.0 (5Gb/s), 4x USB-A 2.0 (480Mb/s), 1x RJ-45 (2.5GBase-T, Realtek), 1x Toslink S/PDIF Out (Realtek), 2x 3.5mm jack (Realtek), 2x antenna connection Quick Connect
- Internal connections1x USB 3.1 Header Key-A (10Gb/s, 1x USB-C), 1x USB 3.0 Header 20-Pin (5Gb/s, 2x USB-A), 2x USB 2.0 Header 9-Pin (480Mb/s, 4x USB-A)
- RAID level0/1/5/10 (B860)
- Expansion slots1x PCIe 5.0 x16, 1x PCIe 4.0 x16 (x4), 1x M.2/M-Key (PCIe 5.0 x4, 2280), 1x M.2/M-Key (PCIe 4.0 x4, 2580/2280), 1x M.2/M-Key (PCIe 4.0 x4, 25110/2580/22110/2280), 1x M.2/E-Key (2230, occupied with WiFi+BT module)
- RGB header1x 4-Pin RGB (+12V/G/R/B, max. 2A), 3x 3-Pin ARGB (+5V/DATA/GND, max. 3A, GIGABYTE Gen2)
- 32GB Corsair Vengeance RGB DDR5-6000 | 2x 16GBThe Corsair Vengeance RAM is one of the most popular RAM series among gamers and offers an outstanding combination of performance, stability, and design. With high clock speeds and low latencies, it ensures that modern games run smoothly and have short load times—even when paired with high-performance processors and graphics cards.
Technical details - RAM type designationDDR5 288-pin DIMM, on-die ECC
- RAM size2 x 16 GB
- RAM total32 GB
- Memory clock Label6000MHz
- Latency38
- RAM coolingHeat Spreader
- be quiet! Pure Rock 3 Black | 120mm PWM fanThe be quiet! Pure Rock 3 is the ideal cooling solution for price-conscious users looking for reliable cooling performance and quiet operation in a compact format. With four powerful heatpipes, a high-quality aluminum heatsink and the proven be quiet! fan design, the Pure Rock 3 offers solid heat dissipation for all common processors - perfect for all-round PCs and gaming systems in the medium performance range.
Technical details - Heatpipes4 heatpipes (6mm)
- TDP190W
- Lighting-
- Dimensions (WxHxD)124x154x71mm (WxHxD)
- Special featuresHeatpipe Direct Touch, black heat sink
- Fan1x 120x120x25mm, 2000rpm, 101.27m³/h, 59.6 CFM, 31.2dB(A), 2.41mmH₂O, 3.6W, single plain bearing (Rifle)
- Socket AMDAM5, AM4
- Socket Intel2011-0/2011-1/2011-3/2066, 1700, 1150/1151/1155/1156/1200
- 500GB brand M.2 SSDNVMe M.2 SSD
Technical details - Memory typedepending on model
- Storage capacity500GB
- Interfaceje nach Modell
- Reading speeddepending on model
- Write speeddepending on model
- SSD controller-
- Mean time between failuresdepending on model
- IOPS 4Kdepending on model
- Power supplydepending on model
- 750W - Corsair SF Series | modular
Technical details - PSU power (Desc)750W
- Power 12V62.5A
- Power 3.3V20A
- Power 5V20A
- Power -12V0A
- PSU certification80 PLUS Platinum
- Volume32.98dB(A) (according to Cybenetics certificate, 115V), 31.72dB(A) (according to Cybenetics certificate, 230V)
- Form factorSFX
- Special featuresErP Lot 6, supports Haswell C6/C7 low-power states, incl. SFX to ATX power supply adapter
- Fan92mm, semi-passive
- 3-year warranty | incl. pick-up & returnWe grant a 3-year warranty on the delivered PC from the date of delivery, including free pick-up & return service in Germany, Austria and Switzerland. If material or manufacturing defects occur during this period, which significantly impair your work with the PC, we will pick up the defective PC or only the defective component (so that you can continue to work with the PC all the time under certain circumstances) free of charge, repair or replace the PC and then make the PC available to you again. Peripherals and accessories (e.g. monitors etc.) are covered by the manufacturer's warranty.
Technical details - Warranty period3 years
- Pick-up and return service3 years
- Telephone supportYes
- Callback serviceYes
- E-mail supportYes
Dimensions
WIDTH x HEIGHT x DEPTH
194x321.5x443mm
Connectivity
Front
1x USB-C 3.1 via USB header Key-A, 2x USB-A 3.0, 1x 3.5mm jack line-out, 1x 3.5mm jack line-in
Rear
1x HDMI 2.1 (HDCP 2.3, iGPU), 1x DisplayPort 2.1 (iGPU), 1x USB4 with DisplayPort 2.1 (40Gb/s, iGPU), 2x USB-A 3.1 (10Gb/s), 4x USB-A 3.0 (5Gb/s), 4x USB-A 2.0 (480Mb/s), 1x RJ-45 (2.5GBase-T, Realtek), 1x Toslink S/PDIF Out (Realtek), 2x 3.5mm jack (Realtek), 2x antenna connection Quick Connect
