ID: 20948
Gaming PC Configurator - Intel 14th Gen (So. 1700)
Intel So. 1700
Intel Core 14th Gen
Max. 8C + 16c
Max. 96GB DDR5 RAM
849
,-
incl. VAT plusShipping
15
,50
Delivery time:
6-8 business days
3 year warranty
Lifetime support
>20 years of experience
/month
3-year warranty,
including pickup and return
Lifetime
Support
Professional
assembly
Rigorous testing and
quality control
Gaming PC Configurator
Intel 14th Gen (So. 1700)
Our PC configurator automatically detects compatibility problems, so that incorrect configuration is virtually impossible. Regardless of this, you can of course call our support team at any time for free advice and configure your desired PC online with the help of our support team. Even as a complete layman!
Every configuration is checked by us when the order is received. We will contact you immediately if there are any problems with the system you have ordered.
Important: We do not consider the absence of components not included in the basic configuration to be a fault - so you do not necessarily have to order a graphics card, hard disk, etc. In this way, we give you the option of upgrading the system yourself with components that you already have or have ordered elsewhere.
Have fun configuring!
The comprehensive gaming PC configurator for Intel 14 Gen So 1700
Technical details
Gaming PC Configurator - Intel 14th Gen (So. 1700)
- Krux Vako Pro, blackThe KRUX Vako Pro stands out with its modern design and well-thought-out layout for high-performance gaming PCs. Ample space for the latest hardware and flexible cooling options make this case an excellent choice for custom PC builds.
Technical details - DesignMidi-Tower
- Mainboard compatibilityMini-ITX (6.7" x 6.7") / µATX (9.6" x 9.6") / ATX (12" x 9.6")
- Fan (front)2x 140 mm, ARGB-lit, or 3x 120 mm (optional)
- Fan (rear)1x 120 mm, ARGB-backlit
- Fan (top)2x 120 mm (optional)
- Fan (lateral)-
- Fan (bottom)-
- Internal drive baysMax. 3x 2.5", max. 2x 3.5"
- ManufacturerKrux
- Connections (CHA)1x USB-C 2.0 (480 Mb/s), 1x USB-A 3.0 (5 Gb/s), 1x USB-A 2.0 (480 Mb/s), 1x 3.5mm jack line-out, 1x 3.5mm jack line-in
- Number of PCIe slots7
- Lighting3-pin ARGB RGB header (+5V/DATA/GND), illuminated fans
- Dimensions (WxHxD)210 x 446 x 376 mm
- Special featuresCable management, dust filter, glass viewing window
- Intel Core i5-14400F, 6C + 4cThe 14th generation Intel Core processors are based on an optimized hybrid architecture that combines powerful performance cores with efficient e-cores. This intelligent distribution of tasks ensures that games and computing-intensive applications run at maximum speed, while background processes are processed in a resource-saving manner. For gamers, this means stable frame rates, fast loading times and an overall smooth gaming experience - even with the latest AAA titles.
Technical details - Processor cores10 (6C+4c)
- BaseIntel 1700 (LGA1700)
- Processor threads16 (12+4)
- Base clock2.50GHz (P-Core), 1.80GHz (E-Core)
- Turbo beat4.70GHz (Turbo Boost 2.0), 4.70GHz (P-Core), 3.50GHz (E-Core)
- L2 cache9.5MB (6x 1.25MB + 4x 512kB)
- L3 cache20MB
- TDP65W (Processor Base Power), 148W (Maximum Turbo Power)
- iGPU type (label)-
- PCIe lanes16x PCIe 5.0, 4x PCIe 4.0
- Memory controllerDual Channel DDR5-5600 (PC5-44800), DDR4-3200 (PC4-25600), 89.6GB/s, max. 192GB
- ManufacturingIntel 7
- Code nameRaptor Lake-S
- MSI B760 Gaming Plus WIFIIntel B760 motherboards are aimed at anyone looking for a balanced combination of performance, features and price. They support the latest Intel processors with LGA1700 sockets and offer a modern platform for gaming systems that need to be reliable and future-proof - without immediately reaching into the high-end class.
Technical details - Processor socketIntel 1700
- RAM support4x DDR4 DIMM, dual PC4-40533U/DDR4-5066 (OC), max. 128GB (UDIMM)
- Wireless standardsWi-Fi 6E (WLAN 802.11a/b/g/n/ac/ax, 2x2, Intel AX211), Bluetooth 5.3
- Form factorATX
- ChipsetIntel B760
- Lighting-
- Special featuresAudio+solid capacitors, 1x M.2 passive cooler, onboard TPM 2.0 support (Intel PTT), white build compatible (PCB primary black)
- ColorSchwarz-Grau-Weiß
- Power supply1x 24-pin ATX, 1x 8-pin EPS12V, 1x 4-pin ATX12V
- FAN header1x CPU fan 4-pin PWM, 5x fan 4-pin PWM, 1x pump 4-pin PW
- Audio descriptionRealtek ALC897
- Connections (rear)1x DisplayPort 1.4 (iGPU), 1x HDMI 2.1 (iGPU), 1x USB-C 3.1 (10Gb/s), 2x USB-A 3.1 (10Gb/s), 4x USB-A 2.0 (480Mb/s), 1x Toslink S/PDIF Out, 5x 3.5mm jack (Realtek ALC897), 1x RJ-45 (2.5GBase-T, Realtek RTL8125BG), 1x PS/2 Combo, 2x antenna connection RP-SMA
- Internal connections1x USB 3.0 Header Key-A (5Gb/s, 1x USB-C), 1x USB 3.0 Header 20-Pin (5Gb/s, 2x USB-A), 2x USB 2.0 Header 9-Pin (480Mb/s, 4x USB-A)
- RAID level0/1/5/10 (B760)
- Expansion slots2x PCIe 4.0 x16 (1x x16, 1x x4), 3x PCIe 3.0 x16 (x1), 1x M.2/M-Key (PCIe 4.0 x4, 22110/2280/2260/2242), 1x M.2/M-Key (PCIe 4.0 x4/SATA, 2280/2260/2242), 1x M.2/E-Key (2230, occupied with WiFi+BT module)
- RGB header1x 4-Pin RGB (+12V/G/R/B, max. 3A), 2x 3-Pin ARGB (+5V/DATA/GND, max. 3A, MSI JARGB_V2)
- 16GB Corsair Vengeance DDR5-6000 | 1x 16GBThe Corsair Vengeance memory is one of the most popular RAM series among gamers and offers an excellent combination of performance, stability and design. With high clock rates and low latencies, it ensures that modern games run smoothly and enable short loading times - even in combination with demanding processors and graphics cards.
Technical details - RAM type designationDDR5 DIMM 288-pin, on-die ECC
- RAM size1x 16GB
- RAM total32GB
- Memory clock Label6000MT/s
- Latency38
- RAM coolingHeatspreader
- Special features-
- Arctic Freezer 36 ARGB | 2x 120mm ARGB Fans
Technical details - Heatpipes4 heat pipes (6 mm)
- TDP200W
- Lightingilluminated fan
- Dimensions (WxHxD)121 x 155 x 87 mm (W x H x D)
- Special featuresHeatpipe Direct Touch, black heat sink
- Fan2x 120x120x25mm, 200–2000 rpm, 82.9 m³/h, 48.79 CFM, 0.3 Sone, 1.85 mmH₂O, 1.32 W, hydrodynamic bearing (FDB) (Arctic P12 PWM PST A-RGB, Link)
- Socket AMDAM5, AM4
- Socket Intel1851/1700
- 500GB brand M.2 SSDNVMe M.2 SSD
Technical details - Memory typedepending on model
- Storage capacity500GB
- Reading speeddepending on model
- Write speeddepending on model
- SSD controller-
- Mean time between failuresdepending on model
- IOPS 4Kdepending on model
- Interfaceje nach Modell
- Power supplydepending on model
- 650W - Endorfy Vero L6
Technical details - PSU power (Desc)650W
- Power 12V54A
- Power 3.3V20A
- Power 5V20A
- Power -12V0A
- PSU certification80 PLUS Bronze
- VolumeETA-Silver (230 V, according to the Cybenetics certificate), LAMBDA-Standard++ (230 V, according to the Cybenetics certificate)
- Form factorATX
- Fan120 mm
- 3-year warranty | incl. pick-up & returnWe grant a 3-year warranty on the delivered PC from the date of delivery, including free pick-up & return service in Germany, Austria and Switzerland. If material or manufacturing defects occur during this period, which significantly impair your work with the PC, we will pick up the defective PC or only the defective component (so that you can continue to work with the PC all the time under certain circumstances) free of charge, repair or replace the PC and then make the PC available to you again. Peripherals and accessories (e.g. monitors etc.) are covered by the manufacturer's warranty.
Technical details - Warranty period3 years
- Pick-up and return service3 years
- Telephone supportYes
- Callback serviceYes
- E-mail supportYes
Dimensions
WIDTH x HEIGHT x DEPTH
210 x 446 x 376 mm
Connectivity
Front
1x USB-C 2.0 (480 Mb/s), 1x USB-A 3.0 (5 Gb/s), 1x USB-A 2.0 (480 Mb/s), 1x 3.5mm jack line-out, 1x 3.5mm jack line-in
Rear
1x DisplayPort 1.4 (iGPU), 1x HDMI 2.1 (iGPU), 1x USB-C 3.1 (10Gb/s), 2x USB-A 3.1 (10Gb/s), 4x USB-A 2.0 (480Mb/s), 1x Toslink S/PDIF Out, 5x 3.5mm jack (Realtek ALC897), 1x RJ-45 (2.5GBase-T, Realtek RTL8125BG), 1x PS/2 Combo, 2x antenna connection RP-SMA
