H200
ID: 22642
5U GPU server configurator - Intel Dual Xeon
Intel Xeon Scalable v5
8x 2.5" Gen5 NVMe/SATA/SAS-4 Hot-Swap
Max. 3,072GB DDR5 ECC RAM
8x NVIDIA H200 HGX
379.669
,-
incl. VAT plusShipping
Pre-order:
1-3 business days
3 year warranty
Lifetime support
30-day return policy
2-year warranty, including
pickup and return service
Lifetime
Support
Professional
assembly
Rigorous testing and
quality control
5U GPU server configurator
Intel Dual Xeon
19" housing in 5U format based on Intel Xeon Scalable (So. 4677) processors.
Technical details
5U GPU server configurator - Intel Dual Xeon
- 5U server enclosure - GigabyteThe Gigabyte G593-SD1 server system offers you maximum performance based on two powerful Intel Xeon Scalable v5 processors. The system's memory can be expanded by 32 DDR5 DIMMs up to 3,072GB to provide more than enough resources for even the most demanding applications and extensive virtualization environments. 8x 2.5" Gen5 NVMe/SATA/SAS-4 hot-swap bays enable the use of fast NVMe SSDs for maximum I/O performance and minimum latency - ideal for data-intensive workloads. The system is equipped with eight NVIDIA H200 HGX accelerators and is therefore ideally equipped for AI, deep learning and complex simulations. Configure the Gigabyte G593-SD1 now according to your individual needs and secure a scalable and future-proof platform for your business-critical applications.
Technical details - Connections (CHA)2x USB 3.2, 1x VGA, 2x 1GB LAN RJ-45, 1x 1GB LAN RJ-45 (Management LAN)
- Number of PCIe slots8x LP x16 (Gen5 x16), 4x FHHL x16 (Gen5 x16)
- Number of hot swap slots8 x 2.5" Gen5 NVMe/SATA/SAS-4
- Number of NVMe drives8 x 2.5" Gen5 NVMe/SATA/SAS-4
- Server power supply4+2 3000W 80 PLUS Titanium
- Number of OCP 3.0 slotsN/A
- CPU support2x Intel LGA 4677
- Main boardGigabyte MSB3-G41
- Number of DIMM slots32x DDR5
- CPU thermal design power350 watts
- Height unit5U
- Dimensions (WxHxD)447mm x 220 mm x 945mm (WxHxD)
- Connections (rear)N/A
- 2x Intel Xeon Silver 4509Y, 8x 2.6GHz, 22.5MB L3 cache5th generation Intel Xeon Scalable processors: The optimized server CPU for top performance. Benefit from more cores, significantly larger cache and faster DDR5 memory on a proven platform with PCIe 5.0 and integrated accelerators. Ideal for demanding AI, HPC and cloud workloads.
Technical details - Processor cores8
- BaseLGA 4677
- Processor threads16
- Base clock2.60 GHz
- Turbo beat4.10 GHz
- L2 cache16MB (8x 2MB)
- L3 cache22.5MB
- TDP125 Watt
- iGPU type (label)N/A
- PCIe lanes80x PCIe 5.0
- Memory controller8 Channel DDR5-4400 (PC5-35200, 281.6GB/s), max. 4TB
- ManufacturingIntel 7
- Code nameSapphire Rapids-SP, Plattform: Eagle Stream
- NVIDIA H200 SXM, 141GB
Technical details - Memory type141GB HBM3e with ECC mode
- API supportN/A
- PCIe cut pointN/A
- GPU typeNVIDIA H200 SXM 141GB
- VRAM141GB
- GPU fanPassive cooling
- Power consumptionN/A
- Dimensions (WxHxD)N/A
- Special featuresN/A
- Power supplyN/A
- Connections (rear)N/A
- 16GB RDIMM ECC DDR5-5600
Technical details - RAM type designationDDR5 RDIMM 288-pin, reg ECC, on-die ECC
- RAM size1x 16GB
- RAM total16GB
- Memory clock Label5600MT/s
- Latency46
- RAM coolingN/A
- Special featuresStandard SPD
Connectivity
Front
2x USB 3.2, 1x VGA, 2x 1GB LAN RJ-45, 1x 1GB LAN RJ-45 (Management LAN)
Rear
N/A, N/A
