ID: 23885
4U server configurator - AMD EPYC
AMD EPYC 9005 Turin
36x 3.5"/2.5" SATA/SAS Hot-Swap
Max. 2,304GB DDR5 ECC RAM
2x 2.5" SATA/SAS Hot-Swap
9.199
,-
incl. VAT plusShipping
168
,00
Pre-order:
approx. 3 months
3 year warranty
Lifetime support
30-day return policy
/month
2-year warranty, including
pickup and return service
Lifetime
Support
Professional
assembly
Rigorous testing and
quality control
4U server configurator
AMD EPYC
19" housing in 4U format based on the AMD EPYC Turin (So. SP5) processors.
Technical details
4U server configurator - AMD EPYC
- 4U server enclosure - GigabyteThe Gigabyte S453-Z30 server system offers you maximum performance based on a powerful AMD EPYC 9005 Turin processor. The system's memory can be expanded by 24 DDR5 DIMMs up to 2,304 GB to provide more than enough resources for even the most demanding applications and extensive virtualization environments. The system's flexible storage solution offers space for up to 36x 3.5"/2.5" SATA/SAS hot-swap bays for cost-efficient mass storage. Configure the Gigabyte S453-Z30 now according to your individual needs and secure a scalable and future-proof platform for your business-critical applications.
Technical details - Connections (CHA)2x USB 3.2
- Number of PCIe slots4x LP x 16 (Gen5 x16)
- Number of hot swap slots36x 3.5"/2.5" SATA/SAS, 2x 2.5" SATA/SAS
- Number of NVMe drivesN/A
- Server power supplyDual 1600W 80 PLUS Titanium
- Number of OCP 3.0 slotsN/A
- CPU support1x AMD SP5
- Main boardGigabyte MZ33-AR0
- Number of DIMM slots24x DDR5
- CPU thermal design power400 watts
- Height unit4U
- Dimensions (WxHxD)482mm x 177mm x 625mm (WxHxD)
- Connections (rear)2x USB 3.2, 1x VGA, 2x 1GB LAN RJ-45, 1x 1GB LAN RJ-45 (Management LAN)
- AMD Epyc 9124, 16x 3.0GHz, 64MB L3 cacheAMD EPYC 9004 Genoa: Unleash extreme computing power and scalability. With up to 96 Zen 4-cores, DDR5 support and PCIe 5.0 for maximum bandwidth - perfect for data centers, HPC and AI applications.
Technical details - Processor cores16
- BaseAMD SP5
- Processor threads32
- Base clock3.00GHz
- Turbo beat3.70GHz
- L2 cache16MB (16x 1MB)
- L3 cache64MB (4x 16MB)
- TDP200W
- iGPU type (label)N/A
- PCIe lanes128x PCIe 5.0
- Memory controller12 Channel DDR5-4800 (PC5-38400, 460.8GB/s), max. 6TB
- ManufacturingZen 4
- Code nameGenoa
- 16GB RDIMM ECC DDR5-5600
Technical details - RAM type designationDDR5 RDIMM 288-pin, reg ECC, on-die ECC
- RAM size1x 16GB
- RAM total16GB
- Memory clock Label5600MT/s
- Latency46
- RAM coolingN/A
- Special featuresStandard SPD
Connectivity
Front
2x USB 3.2
Rear
2x USB 3.2, 1x VGA, 2x 1GB LAN RJ-45, 1x 1GB LAN RJ-45 (Management LAN)
