ID: 152
2U GPU Server Configurator - AMD EPYC
AMD EPYC 9005 Turin
Max. 1,152GB DDR5 ECC RAM
6x 2.5" Gen5 NVMe/SATA/SAS-4 Hot-Swap
Up to 4x NVIDIA H200
16.249
,-
incl. VAT plusShipping
Pre-order:
approx. 1 month
3 year warranty
Lifetime support
>20 years of experience
2-year warranty, including
pickup and return service
Lifetime
Support
Professional
assembly
Rigorous testing and
quality control
2U GPU Server Configurator
AMD EPYC
19" housing in 2U format based on the AMD EPYC Genoa (So. SP5) processors.
Technical details
2U GPU Server Configurator - AMD EPYC
- 2U server enclosure - GigabyteThe Gigabyte XV23-ZX0 server system offers you maximum performance based on two powerful AMD EPYC 9005 Turin processors. The system's memory can be expanded by 24 DDR5 DIMMs up to 2,304GB to provide more than enough resources for even the most demanding applications and extensive virtualization environments. The system's flexible storage solution offers space for up to 6x 2.5" Gen5 NVMe/SATA/SAS-4 hot-swap bays for cost-efficient mass storage. Configure the Gigabyte XV23-ZX0 now according to your individual needs and secure a scalable and future-proof platform for your business-critical applications.
Technical details - Connections (CHA)2x USB 3.2
- Number of PCIe slots7x FHHL x16 (Gen5 x16)
- Number of hot swap slots6 x 2.5" Gen5 NVMe/SATA/SAS-4
- Number of NVMe drives6 x 2.5" Gen5 NVMe
- Server power supply3+1 2000W 80 PLUS Titanium
- Number of OCP 3.0 slotsN/A
- CPU support2x AMD SP5
- Main boardGigabyte MZX3-MG0
- Number of DIMM slots24x DDR5
- CPU thermal design power500 watts
- Height unit2U
- Dimensions (WxHxD)438mm x 87.5mm x 900mm (WxHxD)
- Connections (rear)2x USB 3.2, 1x Mini-DP, 2x 1GB LAN RJ-45, 1x 1GB LAN RJ-45 (Management LAN)
- 2x AMD Epyc 9115, 16x 2.6GHz, 64MB L3 cacheAMD EPYC 9005 Turin: redefine computing power. The advanced Zen 5 architecture delivers breakthrough performance per core, combined with even higher core counts and support for DDR5 and PCIe 5.0. The pinnacle for AI, HPC and future-proof cloud infrastructures.
Technical details - Processor cores16
- BaseAMD SP5
- Processor threads32
- Base clock2.60GHz
- Turbo beat4.10GHz
- L2 cache16MB (16x 1MB)
- L3 cache64MB (4x 16MB)
- TDP155W
- iGPU type (label)N/A
- PCIe lanes128x PCIe 5.0
- Memory controller12 Channel DDR5-6000 (PC5-48000, 576GB/s), max. 6TB
- ManufacturingZen 5
- Code nameTurin
- 16GB RDIMM ECC DDR5-5600
Technical details - RAM type designationDDR5 RDIMM 288-pin, reg ECC, on-die ECC
- RAM size1x 16GB
- RAM total16GB
- Memory clock Label5600MT/s
- Latency46
- RAM coolingN/A
- Special featuresStandard SPD
Connectivity
Front
2x USB 3.2
Rear
2x USB 3.2, 1x Mini-DP, 2x 1GB LAN RJ-45, 1x 1GB LAN RJ-45 (Management LAN)
